Model :HP-Pro Series
The AELAB HP500-Pro LCD Digital Hotplate provides accurate, high-temperature laboratory heating up to 500 °C using a chemical-resistant 10-inch glass ceramic plate. With ±1 °C temperature control accuracy, PT1000 external sensor compatibility, and an intuitive LCD display, the HP500-Pro ensures stable, reproducible thermal performance for research, industrial, and analytical workflows.
Need Help with This Product?
The AELAB HP500-Pro LCD Digital Hotplate is a premium laboratory heating platform engineered for precise temperature control up to 500 °C. Featuring a 10-inch chemical-resistant glass ceramic plate, advanced LCD temperature display, and optional external PT1000 sensor, this hotplate delivers exceptional reliability for research, industrial, and QC applications.
The AELAB HP500-Pro uses an efficient heating module beneath a high-conductivity glass ceramic plate. As current flows through the heating element, heat transfers evenly across the work surface. Users can set temperature and time digitally through the LCD interface. When connected, the PT1000 sensor regulates temperature directly at the sample, ensuring superior accuracy for sensitive applications.
The HP500-Pro incorporates a durable Glass Ceramic work plate engineered for uniform heat transfer and chemical resistance. Its LCD interface displays temperature and time clearly, while an integrated safety system includes a 540 °C protection limit and a “HOT” indicator that activates above 50 °C. The compact 328×424×138 mm body, IP20 protection class, and 1700 W power input make the instrument suitable for continuous laboratory operation.
The heating module distributes thermal energy uniformly across the ceramic plate. Users program the heating range (Room Temp.–500 °C) in 1 °C increments. The onboard controller maintains ±1 °C accuracy, and the PT1000 sensor enables closed-loop feedback directly from the sample vessel. Real-time temperature and timer values are displayed on the LCD for precise process monitoring.
The HP500-Pro includes digital configuration through an integrated LCD controller and supports an external PT1000 temperature probe for real-time feedback. The instrument features onboard runtime recording through the SD card connector (catalog text), enabling GLP-compatible traceability for laboratory documentation.
| Model | Specifications |
|---|---|
| HP500-Pro | 10-inch glass ceramic plate, 500 °C heating range, ±1 °C accuracy, PT1000 sensor compatibility, 1500 W heating output |
The AELAB HP500-Pro is suitable for chemical and biochemical sample preparation, digestion and evaporation procedures, heating of flasks and beakers, method development in R&D labs, QC/QA workflows, and industrial heating applications across pharmaceutical, food, environmental, and materials laboratories.
The HP500-Pro is manufactured following ISO, CE, and GLP-oriented production protocols. All units undergo calibration verification and functional quality control to ensure reliable, traceable performance in regulated laboratory environments.
| Specifications | HP500-Pro |
|---|---|
| Work plate Dimension (W x D) | 254x254mm (10 inch) |
| Work plate material | Glass ceramic |
| Heating position | 1 |
| Heating temperature range | Room Temp.-500°C, increment 1°C |
| Temperature control accuracy | ±1°C (<100°C); ±1% (>100°C) |
| Safety temperature | 540°C |
| Temperature,time display | LCD |
| Timer function | 1min–99h59min |
| Temperature display accuracy | ±0.1°C |
| External temperature sensor | PT1000 (±0.2°C) |
| "Hot" warning | 50°C |
| Protection class | IP20 |
| Power | 1700W |
| Heating output | 1500W |
| Voltage, Frequency | 100–120/200–240V, 50/60Hz |
| Dimension(WxDxH) | 328x424x138mm |
| Weight | 7.2kg |
| Permissible ambient temperature and humidity | 5–40°C, 80%RH |
